PRESIDENT - HARRY-3ASC12/24VOLT - MultiChannel CBMobileTran.
HARRY-3ASC12/24VOLT
New product
By buying this product you can collect up to 1 loyalty point. Your cart will total 1 loyalty point that can be converted into a voucher of 1,00 €.
Pay it by wire
and save an additional 1,18 €
More info
- 40 AM / FM channels
- 12 / 24V
- Rotary channel selector
- Volume and M / A adjustment
- Manual Squelch and ASC
- Large multifunction LCD display
- Level indicator
- VOX function (hands-free)
- ANL anti-parasite filter integrated, NB, HI-CUT
- RF Gain
- Scan channels
- Priority channel storage
- Function key F
- Switchable key beep
- Roger Beep
- AM / FM mode switch
- Key lock
- Front microphone jack
- External HP socket
Lighting color:
Specifications
| Food | : | 13.2 V / 24 V |
| Number of channels | : | 40 |
| AM | : | |
| FM | : | |
| Channel selector | : | rotary |
| Volume | : | Volume and M / A adjustment |
| squelch | : | Manual Squelch |
| ASC | : | Yes |
| display | : | Multifunction LCD |
| Level indicator | : | Digital |
| Vox | : | Yes |
| ANL filter | : | Yes |
| NB filter | : | Yes |
| HI-CUT filter | : | Yes |
| RF-Gain | : | Yes |
| Scan | : | Yes |
| Memory (s) | : | 1 |
| Function key F / Menu | : | Yes |
| Beep of keys | : | Yes |
| Roger beep | : | Yes |
| Key lock | : | Yes |
| Microphone jack | : | in front (6 pines) |
| External Vox microphone jack | : | Yes |
| External HP socket | : | Yes |
| Dimensions | : | 125 (L) x 150 (D) x 45 (H) |
| Weight | : | 0.7 kg |
 |
||
Technical characteristics
| Number of channels | : | 40 |
| Modulation modes | : | AM / FM |
| Frequency range | : | from 26.965 MHz to 27.405 MHz |
| Antenna impedance | : | 50 ohms |
| Supply voltage | : | 12V / 24V |
| Dimensions | : | 125 (L) x 150 (D) x 45 (H) |
| Weight |
| : | 0.7 kg | |
| Accessories included | : | 1 microphone UP / DOWN and its support 1 cradle screw |
| Filtered | : | Integrated ANL (Automatic Noise Limiter) |
| Frequency tolerance | : | +/- 200 Hz |
| Carrier power | : | 4 W AM / 4 W FM |
| Spurious emissions | : | less than 4 nW (- 54 dBm) |
| Frequency response | : | 300 Hz to 3 kHz |
| Power emitted in the adj. | : | less than 20 μW |
| Microphone sensitivity | : | 7 mV |
| Consumption | : | 1.7 A (with modulation) |
| Max. Distortion modulated signal | : | 1.8% |
| Maxi. sensitivity at 20 dB sinad | : | 0.5 μV - 113 dBm |
| Frequency response | : | 300 Hz to 3 kHz |
| Adjacent channel selectivity | : | 60 dB |
| Max audio power | : | 2W |
| Sensitivity of squelch | : | min 0.2 μV - 120 dBm / max 1 mV - 47 dBm |
| Rate of rej. freq. picture | : | 60 dB |
| Frequency rejection rate Intermed. | : | 70 dB |
| Consumption | : | 300 mA nominal / 750 mA max |
